Event 2020 bas v3 studie monitor (1 Stk.) **UDSOLGT**
Event 2020 bas v3 studie monitor (1 Stk.) - Gode studio monitors med 7,1" bas og 1,5" diskant. Denne to-vejs højttaler indeholder en række grundlæggende forbedringer i forhold til den oprindelige model, men er stadig tro i forhold til den tonale karakter og præstation. Event’s ingeniører brugte ideer og teknologier fra flagskibet Opal at opnå resultater i overensstemmelse med virksomhedens design filosofi om høj ydelse, lav forvrængning og fremragende dynamik. På Event’s hjemmeside kan du læse mere om hvilke verdensberømte producere som bruger 20/20bas V3. Bemærk: Pris for 1 stk.
Frequency Response 35Hz - 20kHz ±2dB
Crossover Frequency 2300Hz
3rd Harmonic Distortion @ 90dB SPL, 1m, 500-7kHz 0.08%
3rd Harmonic Distortion @ 90dB SPL, 1m, 200 - 20kHz 0.2%
3rd Harmonic Distortion @ 90dB SPL, 1m, <200Hz 1.5%
Acoustic Output - SPL @ 1m, Long term (80Hz - 20kHz) 105dB
Acoustic Output - SPL @ 1m, Peak (80Hz - 20kHz) 108dB
Signal Input XLR, RCA (balanced/unbalanced)
Frequency Response 20Hz - 20kHz(±0.2dB)
LF Trim Constantly variable ±3dB
HF Trim Constantly variable ±3dB
Subsonic Filter -3dB @ 30Hz
260mmW x 375mmH x 300mmD
17kg
System
- Frequency Response
- 35Hz - 20kHz ±2dB
- Crossover Frequency
- 2300Hz
- 3rd Harmonic Distortion @ 90dB SPL, 1m,
500-7kHz - 0.08%
- 3rd Harmonic Distortion @ 90dB SPL, 1m,
200 - 20kHz - 0.2%
- 3rd Harmonic Distortion @ 90dB SPL, 1m,
<200Hz - 1.5%
- Acoustic Output - SPL @ 1m, Long term
(80Hz - 20kHz) - 105dB
- Acoustic Output - SPL @ 1m, Peak
(80Hz - 20kHz) - 108dB
- Signal Input
- XLR (balanced)
Low Frequency Transducer
- Piston Diameter
- 180mm (7.1")
- Voice Coil Configuration
- High temperature single coil
- Voice Coil Diameter
- 38mm (1.5")
- Former Material
- High-strength Polyamide - Glass Fiber
- Magnet Type
- Ferrite
- Cone Type
- Mineral Filled Polypropylene
- Magnetic Shielding
- Bucking magnet and steel cap
High Frequency Transducer
- Dome Diameter
- 25.4mm (1")
- Voice Coil Diameter
- 25mm (0.98")
- Magnet Type
- Ferrite
- Dome Type
- Silk
- Gap Design
- Ferrofluid Cooled
- Magnetic Shielding
- Bucking Magnet
Amplifier - Low/high frequency
- Frequency Response
- 20Hz - 20kHz(±0.2dB)
- Operating Band Pass
- 20Hz - 2400Hz (LF)/2400Hz - 20kHz (HF)
- Total Harmoic Distortion
- 0.01% 120 Watts into 4 Ohm Load
- Long Term Power @ 4 Ohms
- 80 Watts
- Burst Power @ 4 Ohms
- 120 Watts
- Output Topology
- Class AB
- LF Trim
- Constantly variable ±3dB
- HF Trim
- Constantly variable ±3dB
- Subsonic Filter
- -3dB @ 30Hz
- Driver Protection
- Current Limiting
- Temperature Protection
- Thermal Cut-Off Switch
- Indicators
- Event badge 'On' mode
- Cooling
- Convection - Aluminium Heat Sink
- Power Requirements
- Voltage selector 110-120V or 220-240V, 50/60Hz, 180VA
Power via detachable 3 circuit IEC type linecord
Physical
- Cabinet Construction
- MDF
- Low Frequency Vents
- Front Port
- Cabinet Dimensions
- 260mmW x 375mmH x 310mmD
(10.2"W x 14.8"H x 11.8"D) - Cabinet Weight
- 17kg (37.48lb)
- Shipping Dimensions
- 375mmW x 495mmH x 415mmD
(14.8"W x 19.5"H x 16.3"D) - Shipping Weight
- 19kg (41.88lb)
For mere information, besøg dette produkts hjemmeside.
